DRV-32 Architectural Lighting Dimmer Interface.

The DRV-32 is a lighting control interface providing outputs to control up to 32 dimmer circuits or relays (for lighting or any other purpose).  Incandescent, low voltage, fluorescent, neon, cold cathode and mercury vapor lighting dimmers can be controlled in any combination with any size load via the DRV-32..  Based on a 32-bit Motorola microcontroller,  the DRV-32 can drive most SCR or TRIAC based dimmer and relay modules directly, eliminating the need for any other electronics in the dimmer enclosure.  The DRV-32 accommodates LONWorks. RS-232, RS-485 and other standards.

Additionally the DRV-32 can be expanded to 64 outputs with the addition of an expander option.

MCD-32 Manual Override Control.

The MCD-32 provides manual override of network controlled DRV-32 outputs, with LED level/on/off indication, and status feedback.  Up to 32 channels can be controlled and monitored with the MCD-32.  The MCD-32 is designed to be installed in a standard NEMA enclosure.

Design and specifications subject to change without notice.

Key Benefits

Benefit 1
Benefit 2
Benefit 3


Description SKU # Price
DRV-32 Dimmer Interface sku-1 email
MCD-32 Manual Override sku-2 email
Dimmer Expander Module sku-3 email
